    Details

    The core components of this product adopt imported famous brand surge absorbing devices. After strict screening, the performance is superior and the quality is stable. The product has a built-in semiconductor surge absorbing device with accurate clamping and extremely low residual voltage output. Select the appropriate limiting voltage for different systems to achieve the best protection for the device. This series of products should be selected according to the interface of the equipment or the actual installation requirements, such as interface terminals, RS232, etc. The protection path can be divided into single, double or multi-channel numbers. The number of products can be single or multiple integrated packages.



    Model

    HD-XC-AU

    Nominal working voltage Un

    28V

    Maximum continuous working voltage Uc

    120V

    Nominal discharge current In8/20μs

    2.5KA

    Maximum discharging current Imax8/20μs

    5KA

    Voltage protection level Up

    250V

    Response time Ta

    1ns

    Protection grade

    IP30

    External dimension

    90*62*18mm

    Sheathing material

    Fire-proof material

    Interface mode

    Terminal
